PharmaFluor® PFA Fittings

Description

PharmaFluor® PFA Compression Fittings

Saint-Gobain manufactures PFA fittings for handling corrosive or ultra pure fluids under contamination-free conditions. The PharmaFluor® compression fitting line offers PFA purity combined with the robust performance of compression style fittings. These fittings are ideal for gas or pneumatic connections in applications that do not require flared connections. Once tubing has been cut to the desired length, PharmaFluor® fittings require no tools for installation. The fittings are available in 1/8″”, 1/4″”, 3/8″”, 1/2″”, 3/4″” and 1″” sizes.

We use 100% virgin HP PFA to give you the ultimate in purity and the minimum in contamination. Each PharmaFluor® PFA fitting is carefully inspected to ensure quality and reliability in your application and throughout the life of the product. Fluid handling applications in the biomedical, chemical, petrochemical, food processing and semiconductor industries benefit greatly from the use of these fittings.

Whether it be a simple fluid handling system or a complex laboratory layout, PharmaFluor® PFA fittings save precious time and money, and provide all the reliability needed to facilitate successful outcomes.

Fitting Installation

1. Cut tubing to desired length
2. Loosen nut, insert tube. (your pre assembled fitting should be ready for use)
3. Tighten nut finger-tight.
4. Your fitting is now ready for use.

No tools are required, but if you decide to use a mechanical device to tighten it, rotate the nut no more than one turn past finger-tight.

Features / Benefits :

• Simple design for ease of installation
• No special tools required
• Accommodates temperatures up to 212°F (100°C)

Materials of Construction

• Body: high purity PFA
• Gripper: PVDF
• Ferrule: PTFE
• Nut: ETFE
